L-Acoustics
View more 12XT
View more Custom Speakers
| Quantity | 4 |
| Condition | Excellent / Few Scratches |
| Location | Europe |
| Previous Use | Touring |
| Warranty | 7 Day |
Ultimate sonic performance, clarity and precision
Point source radiation with excellent off-axis performance
FOH, fill, monitor versatility for reduced inventory
Plug and play for fast set-up and reduced tuning time
Integrated rigging system for distributed SR applications
Sleek design, durable construction, extended longevity
LA4 advanced system drive and protection
The 12XT active/passive cabinet is the mid sized model of the L-ACOUSTICS® XT coaxial series and has an operating frequency bandwidth of 55 Hz to 20 kHz. This response can be lowered to 32 Hz with the addition of the SB18 subwoofer.
The 12XT enclosure contains a 3’’ diaphragm compression driver coaxially loaded by a 12’’ low frequency transducer mounted in a bass-reflex tuned enclosure. In passive configuration, the 12XT onboard crossover network uses proprietary third order filters. The linearization and protection of the transducers is defined by the drive parameters contained in the amplified controllers.
The coaxial transducer arrangement produces a 90° axi-symmetric directivity output along with a smooth tonal response free of any secondary lobes over the entire frequency range.
Made of high-grade Baltic birch plywood, the cabinet design makes the 12XT perfectly suited to all multi-purpose sound reinforcement applications. Its wedge-shape allows short or long throw monitoring use with two fixed angle settings of 30˚ and 60° from vertical. The 12XT can also be pole-mounted using the integrated socket or flown using the complementary ETR12-2 bracket, XTLIFTBAR accessory or a 3rd party Omnimount® fixture.
checked and tested by official L-acoustic technical department.
12XT |
| L-Acoustics |
| All 12XT |
| 5 Available |
| $1,452 USD |
| €1.200 EUR |
| View » |
12XT |
| L-Acoustics |
| All 12XT |
| 10 Available |
| $1,510 USD |
| €1.248 EUR |
| View » |
12XT |
| L-Acoustics |
| All 12XT |
| 8 Available |
| $1,694 USD |
| €1.400 EUR |
| View » |
8XT |
| L-Acoustics |
| All 8XT |
| 19 Available |
| $980 USD |
| €810 EUR |
| View » |
Kiva |
| L-Acoustics |
| All 8XT |
| 5 Available |
| $1,089 USD |
| €900 EUR |
| View » |
8XT |
| L-Acoustics |
| All 8XT |
| 5 Available |
| $1,089 USD |
| €900 EUR |
| View » |
8XT |
| L-Acoustics |
| All 8XT |
| 8 Available |
| $1,089 USD |
| €900 EUR |
| View » |
8XT |
| L-Acoustics |
| All 8XT |
| 3 Available |
| $1,234 USD |
| €1.020 EUR |
| View » |
12XT |
| L-Acoustics |
| All 12XT |
| 5 Available |
| $1,452 USD |
| €1.200 EUR |
| View » |
12XT |
| L-Acoustics |
| All 12XT |
| 10 Available |
| $1,510 USD |
| €1.248 EUR |
| View » |
12XT |
| L-Acoustics |
| All 12XT |
| 8 Available |
| $1,694 USD |
| €1.400 EUR |
| View » |
HDQ-4K35 |
| Barco |
| All HDQ-4K35 |
| 3 Available |
| $34,000 USD |
| €29.529 EUR |
| View » |
MAC Quantum Profile |
| Martin Professional |
| All MAC Quantum Pr... |
| 26 Available |
| $3,812 USD |
| €3.150 EUR |
| View » |
VL4000 Spot |
| Vari-Lite |
| All VL4000 Spot |
| 60 Available |
| $3,795 USD |
| €3.296 EUR |
| View » |
MAC Viper Performance |
| Martin Professional |
| All MAC Viper Perf... |
| 30 Available |
| $7,395 USD |
| €6.423 EUR |
| View » |
J-Series |
| db audiotechnik |
| All J-Series |
| 1 Available |
| $302,200 USD |
| €249.750 EUR |
| View » |
WildBeam |
| Ayrton |
| All WildBeam |
| 100 Available |
| $990 USD |
| €860 EUR |
| View » |
VT4882 |
| JBL |
| All VT4882 |
| 4 Available |
| $1,000 USD |
| €868 EUR |
| View » |
KIVA |
| L-Acoustics |
| All KIVA |
| 60 Available |
| $1,597 USD |
| €1.320 EUR |
| View » |
Founded by Dr Christian Heil in 1984, L-ACOUSTICS has revolutionized the Pro Audio industry with its legendary Line Source Systems.For the past two decades, L-ACOUSTICS has developed a reputation for creating innovative solutions to the most...
Engineers at the Helsinki Music Hall in Finland have completed the installation of a new KIVA WST line source system.The 17,000-seater hall is used by the Helsinki Philharmonic Orchestra, the Sibelius Academy and the Radio Symphony Orchestra, amongst others, and is also booked throughout the year for various concerts.The L-...
Producers of the famed TV game show Wheel of Fortune adopted an L-ACOUSTICS KARA system for the filming of 15 episodes of the show on location in New Orleans,Louisiana.Filming took place last month over a period of three days - with the 15 episodes said to be enough for three weeks worth of the show's broadcasts - in front ...
LeedsUniversity's1,000 capacity Stylus , an all purpose venue used bystudentsfor a range concerts and liveperformances, has been outfitted with a brand new L-ACOUSTICS KARAi system as part of a major refurbishment.The installation was a tricky one, as it involved fitting 6 KARAi's on each side of the venue, and it had to be...
A new branch of the famous Nomads Club has opened its doors in the Turkish capital Istanbul, boasting a new L-ACOUSTICS coaxial sound system installation.Nomads Istanbul, as the club is known, closely follows the original Amsterdam venue concept, doling out an exotic fusion of Eastern and European cultures in both its cuisi...
The 12XT active/passive cabinet is the mid sized model of the L-Acoustics XT coaxial series and has an operating frequency bandwidth of 55 Hz to 20 kHz. This response can be lowered to 32 Hz with the addition of the SB18 Subwoofer.
The 12XT enclosure contains a 3'' diaphragm Compression Driver coaxially loaded by a 12'' low frequency transducer mounted in a bass-reflex tuned enclosure. In passive configuration, the 12XT onboard crossover network uses proprietary third order filters. The linearization and protection of the transducers is defined by the drive parameters contained in the amplified controllers.
The coaxial transducer arrangement produces a 90deg axi-symmetric directivity output along with a smooth tonal response free of any secondary lobes over the entire frequency range.
Made of high-grade Baltic birch plywood, the cabinet design makes the 12XT perfectly suited to all multi-purpose sound reinforcement applications. Its wedge-shape allows short or long throw monitoring use with two fixed angle settings of 30˚ and 60deg from vertical. The 12XT can also be pole-mounted using the integrated socket or flown using the complementary ETR12-2 bracket, XTLIFTBAR accessory or a 3rd party Omnimount fixture.
The 12XT is driven by the L-Acoustics amplified controllers in the following active or passive modes (selectable by an active/passive switch behind the front grill):
* ''FULL RANGE'' mode for standalone use of 12XT at nominal bandwidth ([12XTA_FR], [12XTA_FI], [12XTA_MO], [12XTP_FR], [12XTP_FI] and [12XTP_MO] presets)
* ''HIGH-PASS'' mode with 100 Hz high-pass filter to possibly associate the complementary SB18 Subwoofer (same presets as above with ''_100'' extension)
For each mode a distinction is drawn between [FRONT], [FILL] and [MONITOR] presets as they respectively match front of house, distributed applications and half-space loading operating conditions.
The performances of the 12XT enclosure depend upon the choice of preset and physical system configuration.
