Used ALC-6 Amp | For Sale Item# 47775

Alcons Audio
Alcons Audio
View more ALC-6 Amp
View more Amp Rack Units

Call for more information. (404) 817-9300

Quantity 2
Condition Excellent / Few Scratches
Year 2013
Location Europe
Case Type Single
Previous Use Touring
Warranty 7 Day

Description

Protection: The speaker is protected against damage from over-excursion and power overload.
Dedicated filtering: The fixed cross-over settings cater for the best system performance.
Optimised power response: The SDP module adjusts the RMS and peak values to the speakers capacity, giving maximum system power output.
System equalising: This circuit equalises the system response, with utilising the maximum component efficiency. This results in higher overall system sensitivity and reduces the need for active filtering while offering efficient amplifier usage (passive system).

The ALC6 is a combination of a speaker controller and power amplifier. The ALC units are designed to guarantee the best speaker drive, with maximum sound quality and operating reliability. The controller section consist of several stages; On the input stage the SDP circuit and on the output stage the SIS circuit ensure easy, reliable and optimised speaker response.

What's Included

flightcase

(Unit Price)
$1,763 USD
(Unit Price)
€1.440 EUR
Financing Available
Minimum Order of 0 Units
(Price for 0 units)
(Price for 0 units)
Ask About This Product

Call: (404) 817.9300

Newsletter Sign Up

Receive our Latest Deals
Sign Up Here

Featured Deals

Our Best Deals
View All

Can't Find it?

We can source it for you.
Tell Us What You Need
Database Error
Message:MySQL Query fail: select MODEL, items.ID_REG_MODEL, registered_manufacturers.REGISTERED_MANUFACTURER, registered_models.REGISTERED_MODEL, MANUFACTURER, registered_manufacturers.ID_REG_MANUF, ID_ITEM, SUBTITLE, items.DESCRIPTION, PRICE_FINAL_US, QUANTITY, AGE_DOM, CONDITION_COSMETIC, WARRANTY_TYPE_NUMBER, WARRANTY_TYPE_UNIT, REGION_WEBSITE, CURRENCY_CODE, STATUSS, LARGE_SYSTEM, EXTRA_VAR_3, category_1.ID_CATEGORY_1, category_1.NAME_1, category_2.ID_CATEGORY_2, category_2.NAME_2, category_3.ID_CATEGORY_3, category_3.NAME_3, category_1.PRIORITY_1, category_2.PRIORITY_2, category_3.PRIORITY_3, MAKE_OFFER, CREATE_DATE, DATE_POSTED, CASE CURRENCY_CODE when 'USD' then ceiling( PRICE_FINAL_US * 1) when 'EUR' then ceiling( ( PRICE_FINAL_US * ( 1 / 0.8372) ) * 1.025 ) when 'GBP' then ceiling( ( PRICE_FINAL_US * ( 1 / 0.7362) ) * 1.025 ) when 'CAD' then ceiling( ( PRICE_FINAL_US * ( 1 / 1.2196) ) * 1.025 ) end as price_converted_usd from items LEFT JOIN contacts USING(ID_COMPANY) LEFT JOIN data_prefs_location_countries ON (contacts.ID_COUNTRY = data_prefs_location_countries.ID_COUNTRY) LEFT JOIN data_prefs_location_regions ON (data_prefs_location_countries.ID_REGION = data_prefs_location_regions.ID_REGION) LEFT JOIN registered_models ON ( items.ID_REG_MODEL = registered_models.ID_REG_MODEL ) LEFT JOIN registered_manufacturers ON ( registered_manufacturers.ID_REG_MANUF = registered_models.ID_REG_MANUF ) LEFT JOIN category_3 ON ( items.CATEGORY_MAIN = category_3.ID_CATEGORY_3 ) LEFT JOIN category_2 ON ( category_2.ID_CATEGORY_2 = category_3.ID_PARENT_3 ) LEFT JOIN category_1 ON ( category_1.ID_CATEGORY_1 = category_2.ID_PARENT_2 ) where PRICE_FINAL_US >0 && QUANTITY >0 && CONTACT_STANDING = 1 && ID_ITEM != 47775 && STATUSS IN ('FOR_SALE','BSTOCK') && items.ID_REG_MODEL = '11950' GROUP BY ID_ITEM ORDER BY FIELD(STATUSS, 'NEW','FOR_SALE','BSTOCK'), FIELD(EXTRA_VAR_3, '1','2','3','8','9','0'), FIELD(TOP_MODEL, '1','2','3','4','5','0'), PRICE_FINAL_US asc LIMIT 40
MySQL Error:Got error 28 from storage engine
Date:Friday, November 24, 2017 at 10:51:06 PM
Script:/used/alc-6-amp/47775
Database Error
Message:Result ID: could not be freed.
MySQL Error:Got error 28 from storage engine
Date:Friday, November 24, 2017 at 10:51:06 PM
Script:/used/alc-6-amp/47775
Database Error
Message:MySQL Query fail: select MODEL, items.ID_REG_MODEL, registered_manufacturers.REGISTERED_MANUFACTURER, registered_models.REGISTERED_MODEL, MANUFACTURER, registered_manufacturers.ID_REG_MANUF, ID_ITEM, SUBTITLE, items.DESCRIPTION, PRICE_FINAL_US, QUANTITY, AGE_DOM, CONDITION_COSMETIC, WARRANTY_TYPE_NUMBER, WARRANTY_TYPE_UNIT, REGION_WEBSITE, CURRENCY_CODE, STATUSS, LARGE_SYSTEM, EXTRA_VAR_3, category_1.ID_CATEGORY_1, category_1.NAME_1, category_2.ID_CATEGORY_2, category_2.NAME_2, category_3.ID_CATEGORY_3, category_3.NAME_3, category_1.PRIORITY_1, category_2.PRIORITY_2, category_3.PRIORITY_3, MAKE_OFFER, CREATE_DATE, DATE_POSTED, CASE CURRENCY_CODE when 'USD' then ceiling( PRICE_FINAL_US * 1) when 'EUR' then ceiling( ( PRICE_FINAL_US * ( 1 / 0.8372) ) * 1.025 ) when 'GBP' then ceiling( ( PRICE_FINAL_US * ( 1 / 0.7362) ) * 1.025 ) when 'CAD' then ceiling( ( PRICE_FINAL_US * ( 1 / 1.2196) ) * 1.025 ) end as price_converted_usd from items LEFT JOIN contacts USING(ID_COMPANY) LEFT JOIN data_prefs_location_countries ON (contacts.ID_COUNTRY = data_prefs_location_countries.ID_COUNTRY) LEFT JOIN data_prefs_location_regions ON (data_prefs_location_countries.ID_REGION = data_prefs_location_regions.ID_REGION) LEFT JOIN registered_models ON ( items.ID_REG_MODEL = registered_models.ID_REG_MODEL ) LEFT JOIN registered_manufacturers ON ( registered_manufacturers.ID_REG_MANUF = registered_models.ID_REG_MANUF ) LEFT JOIN category_3 ON ( items.CATEGORY_MAIN = category_3.ID_CATEGORY_3 ) LEFT JOIN category_2 ON ( category_2.ID_CATEGORY_2 = category_3.ID_PARENT_3 ) LEFT JOIN category_1 ON ( category_1.ID_CATEGORY_1 = category_2.ID_PARENT_2 ) where PRICE_FINAL_US >0 && QUANTITY >0 && CONTACT_STANDING = 1 && items.CATEGORY_MAIN = 5 && STATUSS IN ('FOR_SALE','BSTOCK') && items.CATEGORY_MAIN = '5' GROUP BY ID_ITEM ORDER BY FIELD(STATUSS, 'FOR_SALE','NEW','BSTOCK'), FIELD(EXTRA_VAR_3, '1','2','3','8','0','9'), FIELD(TOP_MODEL, '1','2','3','4','5','0'), PRICE_FINAL_US asc LIMIT 8
MySQL Error:Got error 28 from storage engine
Date:Friday, November 24, 2017 at 10:51:06 PM
Script:/used/alc-6-amp/47775
Database Error
Message:Result ID: could not be freed.
MySQL Error:Got error 28 from storage engine
Date:Friday, November 24, 2017 at 10:51:06 PM
Script:/used/alc-6-amp/47775
Database Error
Message:MySQL Query fail: select MODEL, items.ID_REG_MODEL, registered_manufacturers.REGISTERED_MANUFACTURER, registered_models.REGISTERED_MODEL, MANUFACTURER, registered_manufacturers.ID_REG_MANUF, ID_ITEM, SUBTITLE, items.DESCRIPTION, PRICE_FINAL_US, QUANTITY, AGE_DOM, CONDITION_COSMETIC, WARRANTY_TYPE_NUMBER, WARRANTY_TYPE_UNIT, REGION_WEBSITE, CURRENCY_CODE, STATUSS, LARGE_SYSTEM, EXTRA_VAR_3, category_1.ID_CATEGORY_1, category_1.NAME_1, category_2.ID_CATEGORY_2, category_2.NAME_2, category_3.ID_CATEGORY_3, category_3.NAME_3, category_1.PRIORITY_1, category_2.PRIORITY_2, category_3.PRIORITY_3, MAKE_OFFER, CREATE_DATE, DATE_POSTED, CASE CURRENCY_CODE when 'USD' then ceiling( PRICE_FINAL_US * 1) when 'EUR' then ceiling( ( PRICE_FINAL_US * ( 1 / 0.8372) ) * 1.025 ) when 'GBP' then ceiling( ( PRICE_FINAL_US * ( 1 / 0.7362) ) * 1.025 ) when 'CAD' then ceiling( ( PRICE_FINAL_US * ( 1 / 1.2196) ) * 1.025 ) end as price_converted_usd from items LEFT JOIN contacts USING(ID_COMPANY) LEFT JOIN data_prefs_location_countries ON (contacts.ID_COUNTRY = data_prefs_location_countries.ID_COUNTRY) LEFT JOIN data_prefs_location_regions ON (data_prefs_location_countries.ID_REGION = data_prefs_location_regions.ID_REGION) LEFT JOIN registered_models ON ( items.ID_REG_MODEL = registered_models.ID_REG_MODEL ) LEFT JOIN registered_manufacturers ON ( registered_manufacturers.ID_REG_MANUF = registered_models.ID_REG_MANUF ) LEFT JOIN category_3 ON ( items.CATEGORY_MAIN = category_3.ID_CATEGORY_3 ) LEFT JOIN category_2 ON ( category_2.ID_CATEGORY_2 = category_3.ID_PARENT_3 ) LEFT JOIN category_1 ON ( category_1.ID_CATEGORY_1 = category_2.ID_PARENT_2 ) where PRICE_FINAL_US >0 && QUANTITY >0 && CONTACT_STANDING = 1 && EXTRA_VAR_3 IN ('1','2','3') && STATUSS IN ('FOR_SALE','BSTOCK') GROUP BY ID_ITEM ORDER BY FIELD(STATUSS, 'FOR_SALE','NEW','BSTOCK'), FIELD(EXTRA_VAR_3, '1','2','3','8','0','9'), FIELD(TOP_MODEL, '1','2','3','4','5','0'), PRICE_FINAL_US asc LIMIT 8
MySQL Error:Got error 28 from storage engine
Date:Friday, November 24, 2017 at 10:51:06 PM
Script:/used/alc-6-amp/47775
Database Error
Message:Result ID: could not be freed.
MySQL Error:Got error 28 from storage engine
Date:Friday, November 24, 2017 at 10:51:06 PM
Script:/used/alc-6-amp/47775

Alcons Audio | Solaris

Product Information

ALC-6 Amp

ALC-6 Amp

Database Error
Message:MySQL Query fail: select REGISTERED_MODEL, ID_REG_MODEL, registered_manufacturers.REGISTERED_MANUFACTURER FROM registered_models LEFT JOIN registered_manufacturers ON ( registered_manufacturers.ID_REG_MANUF = registered_models.ID_REG_MANUF ) where REGISTERED_MODEL REGEXP '[[:alnum:]]+' && SEO_EXCLUDE_KEYWORD != 1 && LENGTH(REGISTERED_MODEL) >= 5 order by rand()
MySQL Error:Error writing file '/var/tmp/MYBWmTD1' (Errcode: 28 - No space left on device)
Date:Friday, November 24, 2017 at 10:51:07 PM
Script:/used/alc-6-amp/47775
The ALC6 is a combination of a speaker controller and power amplifier. The ALC units are designed to guarantee the best speaker drive, with maximum sound quality and operating reliability.
The controller section consist of several stages; On the input stage the SDP circuit and on the output stage the SIS circuit ensure easy, reliable and optimised speaker response.

The controller section consist of several stages; On the input stage the SDP circuit and on the output stage the SIS circuit ensure easy, reliable and optimised speaker response.









SDP Speaker Drive Processor




The SDP circuit can be seen as the brain of the amplifier. By means of speaker-specific modules, that are located in 2 front-accessible slots, the characteristics of the connected speaker are loaded into the amplifier. With this, the amplifier is tailor-made to the speaker, regardless of the power output specifications of the amplifier. This can be done with either the analogue SDP modules, or the DDP digital drive processor.
Multiple processing functions are operating at the same time;

protection: The speaker is protected against damage from over-excursion and power overload.
dedicated filtering: The fixed cross-over settings cater for the best system performance.
optimised power response: The SDP module adjusts the RMS and peak values to the speakers capacity, giving maximum system power output.
system equalising: This circuit equalises the system response, with utilising the maximum component efficiency. This results in higher overall system sensitivity and reduces the need for active filtering while offering efficient amplifier usage (passive system).
The DDP also offers level control, mute and a user-controllable 4-band parametric equaliser and (up to) 340ms delay.
By placing the modules in the slots, the SDP circuit is automatically activated, without the need for changing switches/jumpers (plug&play). Taking out the modules, bypasses the SDP circuit and converts the ALC into a standard stereo power ampli- fier, for use with traditional speaker systems.


SIS Signal Integrity Sensing




The SIS circuit extends the control-loop of the amplifier to the input terminals of the speaker, by means of two additional (sense) wires, compensating for the influence of speaker Cables.
SIS offers cable-length independent damping, resulting in a virtually infinite damping under all conditions (up to an almost immeasurable value of over 10.000).
Furthermore SIS maintains signal level by detecting the amount of signal loss at the end of the cable. As a result of pre-compensation of the self-induction of the cable, non-linear harmonic + intermodulation distortion are reduced substantially by SIS, while offering a more linear frequency response (reduced linear distortion).

SIS offers a significantly tighter and more accurate low and mid response. Without connection of the 2 extra sense wires, the ALC units can also be used as any normal amplifier in combination with non- SIS speaker systems.


ATCM Advanced Thermal and Clip Management



ATCM has a number of sensors within the ampli- fier, that constantly monitor both operating temperature, in and output signal. For the temperature section of ATCM, the input signal stage is regulated when dangerous temperature increase is sensed; In this way, the amplifier stays in operation, instead of switching into heat protection.
The clip limiter section reduces the signal input level to the safest maximum level, when continuous clipping is detected. In this way the high frequency drivers are protected against damage from harmonics and also the amplifier remains cooler. The clip limiter reduces overdrive peaks, allowing a higher average output level without audible distortion.

ATCM offers ease-of-operation and guarantees operation under all conditions.


data port




The Data port located on the back of the unit, is the connection for ALC remote-control function.
Through the 15-pin D-connection to remote processor, function includes indication of operating status; Temperature per channel, bridge/parallel mode, AC power level, output power read-out, impedance check for speaker damage, clip/protect indication, level control, etc.
For cinema application, the Data-port is completely compatible with existing D-pin connected cinema Monitors. In that application, the signal in/out connection also caters for reduced set-up and installation time and standardised in/output levels.


operation




The ALC6 amplifier has in addition a number of user-friendly features, that make the ALC the ideal Alcons speaker companion;
All relevant switches (bridge and parallel input) are conveniently located on the front behind the cover.

When switching to bridge-mode, there is no need for using different SDP modules. Furthermore, in bridge-mode, the amp is controlled by only one channel.

The parallel-mode input switch; With this switch, the input of channel 1 is also send to input channel 2. Therefore there is no need for external loop wires (Y-Cables) from link output 1 into input 2.

The ALC features PowerCon AC power connection, for quick and efficient exchange of rack mounted ALCs.

The ALC6 is also available in stealth version; The ALC6st has potentiometers that are located behind the front lid, preventing unwanted changing of gain-settings.
