256 DMX fixtures 32 channels each12 groups fixtures assign.
Parallel running of the 4 tracks (32 scenes each) in each group.Cycle, Rebound and Single modes of the scenes run.Manual positioning between scenes.Adjustable Time and Fade-OUT for each scene.
Extra tracks for all fixtures:DMX input (1 scene), Timecode (512 scenes), Accents (1 scene).
Dimmers Master-fader for each group. 2 masters presets with X-Fader.
2 parallel groups streams - Basic and Background.X-Faders between streams for each group. Manual and automatic modes.
Control accuracy - 32 bit per channel, 1 ms.
DMX output: 4 signal lines 512 channels each.DMX input: 1 signal line, 512 channels.
File system
1000 files for each group.1000 file-lists with all groups information.
Independed fixtures types: movingheads, scanners, effects, dimmers etc.1000 files of screen drivers for each fixtures type.
3D realtime visualization (26 FPS)
256 different type fixtures visualization.
Rectangular room with adjustable wallpapers.256 furniture objects in the room.
Fixtures body visualization.Fixtures objective visualization.Complete photometric rays visualization.
For each fixture- photo Gobos (3 wheels),- photo colors (3 wheels),- effects of Zoom, Iris, Prism, Dimmer, Strobo, CMY.- wheels rotation for colors and Gobos.- Gobos and prism rotation.- photo shadow for gobo projection from all room furnitures.- manual ray positioning on the room walls.
Manual adjust of the room view.Automatic horizontal and vertical rotate of the room view.
System requirements
Minimum configuration- CPU `AMD Duron` or `Intel Pentium-2 300 mHz`,- videocard `nVidia GeForce-2 MX/MX400` or `ATI Radeon 9000` (16 Mb)- RAM 128 Mb- OS `Windows 98-SE`, `DirectX 8.0`- HDD free space 100 Mb
Recomended configuration- CPU `AMD Athlon XP 2500+`- 128 bit videocard `nVidia GeForce FX-5600 Ultra` or 'ATI Radeon 9600 Pro' (128 Mb)- RAM 256 Mb- OS `Windows XP`- HDD free space 1 Gb
